| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFB-1100-B | 1 | Male Clamp Plug | B | for RG-174/U | N/A | N | G | T | $3.15 | $3.05 | $2.95 |
| RFB-1100-C2ST | 1 | Male Clamp Plug | C2 | for Times LMR-200 | N/A | S | G | T | $4.09 | $3.99 | $3.89 |
| RFB-1100-2 | 1 | Male Clamp Plug | C, C1 | for RG-58/U & RG-142/U | UG-88D/U | N | G | D | $2.33 | $2.23 | $2.13 |
| RFB-1100-2ST | 1 | Male Clamp Plug | C, C1 | for RG-58/U & RG-142/U | UG-88/U, C/U, D/U, E/U | S | G | T | $3.15 | $3.05 | $2.95 |
| RFB-1101-PL | 2 | Male Clamp Plug | PL | for Belden 89913 Plenum | N/A | S | G | T | $6.01 | $5.91 | $5.81 |
| RFB-1101-1EN | 2 | Male Clamp Plug | E | for RG-8/U | UG-959A/U | N | G | D | $5.86 | $5.76 | $5.66 |
| RFB-1101-1P | 1 | Male Clamp Plug | P | for Proflex | N/A | N | S | T | $3.08 | $2.98 | $2.88 |
| RFB-1101-1SI | 2 | Male Clamp Plug | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $5.31 | $5.21 | $5.11 |
| RFB-1101-1X | 1 | Male Clamp Plug | X | for RG-8/X & Times LMR-240 | N/A | N | S | D | $2.85 | $2.75 | $2.65 |
| RFB-1102-T | 3 | Male Solderness Clamp Plug | C, C1 | for RG-58/U & RG-142/U | N/A | N | S | T | $3.31 | $3.21 | $3.11 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFB-1104 | 4 | Male Twist-on Plug | C | for RG-58/U | N/A | N | S | D | $2.21 | $2.11 | $2.01 |
| RFB-1106-C1ST | 5 | Male Crimp Plug | C1 | for RG-142/U | N/A | S | G | T | $3.44 | $3.34 | $3.24 |
| RFB-1106-C2 | 5 | Male Crimp Plug | C2 | for Times LMR-200 | N/A | N | G | T | $2.13 | $2.03 | $1.93 |
| RFB-1106-C2ST | 5 | Male Crimp Plug | C2 | for Times LMR-200 | N/A | S | G | T | $3.27 | $3.17 | $3.07 |
| RFB-1106-C2T | 5 | Male Crimp Plug | C2 | for Times LMR-200 | N/A | N | G | T | $3.05 | $2.95 | $2.85 |
| RFB-1106-2 | 5 | Male Crimp Plug | C | for RG-58/U | UG-1785/U | N | G | D | $1.97 | $1.87 | $1.77 |
| RFB-1106-2ST | 5 | Male Crimp Plug | C | for RG-58/U | UG-1785/U | S | G | T | $2.64 | $2.54 | $2.44 |
| RFB-1106-2T | 5 | Male Crimp Plug | C | for RG-58/U | UG-1785/U | N | G | T | $2.21 | $2.11 | $2.01 |
| RFB-1106-2TC1 | 5 | Male Crimp Plug | C1 | for RG-142/U | N/A | N | G | T | $3.15 | $3.05 | $2.95 |
| RFB-1106-5 | 6 | Male Crimp Plug | B | Large Ferrule, for RG-174/U | N/A | N | G | T | $2.48 | $2.38 | $2.28 |
| RFB-1106-5B1 | 6 | Male Crimp Plug | B1 | Large Ferrule, for RG-316 Double Shield | N/A | N | G | T | $3.50 | $3.40 | $3.30 |
| RFB-1106-6 | 7 | Male Crimp Plug | B | Small Ferrule, for RG-174/U | N/A | N | G | T | $2.53 | $2.43 | $2.33 |
| RFB-1106-9 | 8 | Male Quick Disconnect Crimp Plug | C | UNiversal for BNC, TNC, & N, for RG-58/U | N/A | N | G | D | $2.42 | $2.32 | $2.22 |
| RFB-1107-1P | 5 | Male Crimp Plug | P | for Proflex | N/A | N | G | D | $2.10 | $2.00 | $1.90 |
| RFB-1107-1X | 5 | Male Crimp Plug | X | for RG-8/X & Times LMR-240 | N/A | N | G | D | $2.10 | $2.00 | $1.90 |
| RFB-1107-7 | 5 | Male Crimp Plug | M | for Motorola White Teflon, Belden 89907 | N/A | N | G | D | $2.69 | $2.59 | $2.49 |
| RFB-1110-C-04 | 9 | Male Right Angle Clamp Plug | C, C1 | for RG-58/U & RG-142/U | N/A | S | G | T | $6.25 | $6.15 | $6.05 |
| RFB-1110-C1 | 10 | Male Right Angle Crimp Plug | C1 | for RG-142/U | N/A | N | G | T | $5.92 | $5.82 | $5.72 |
| RFB-1110-C2 | 10 | Male Right Angle Crimp Plug | C2 | for Times LMR-200 | N/A | N | G | T | $6.64 | $6.54 | $6.44 |
| RFB-1110-C2S | 11 | Male Right Angle Clamp Plug | C2 | for Times LMR-200 | N/A | S | S | T | $8.13 | $8.03 | $7.93 |
| RFB-1110-S | 11 | Male Right Angle Clmp Plug | C | for RG-58/U | UG-913/U, A/U | S | S | T | $6.24 | $6.14 | $6.04 |
| RFB-1110-1 | 10 | Male Right Angle Crimp Plug | C | for RG-58/U | N/A | N | G | T | $4.91 | $4.81 | $4.71 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFB-1111 | 12 | Female Right Angle PCB Mount | with Triple D-Flat, Diecast Zinc | N/A | N | G | P | $2.88 | $2.78 | $2.68 | |
| RFB-1111-04 | 12 | Female Right Angle PCB Mount | with D-Flat, Diecast Zinc, No Hardware | N/A | N | G | P | $2.47 | $2.37 | $2.27 | |
| RFB-1111-1 | 13 | Female Vertical PCB Mount | with Triple D-Flat, Diecast Zinc | N/A | N | G | P | $3.52 | $3.42 | $3.32 | |
| RFB-1111-1-04 | 13 | Female Vertical PCB Mount | with Tripke D-Flat, Diecast Zinc, No Hardware | N/A | N | G | P | $2.62 | $2.52 | $2.42 | |
| RFB-1112-B | 14 | Female R/A Lo-Profile PCB Mount | with D-Flat & Post Legs, Black | N/A | A | G | P | $2.00 | $1.90 | $1.80 | |
| RFB-1112-B-03 | 15 | Female R/A Lo-Profile PCB Mount | with D-Flat & Snap Legs, Black | N/A | A | G | P | $2.16 | $2.06 | $1.96 | |
| RFB-1112-B-04 | 14 | Female R/A Lo-Profile PCB Mount | with D-Flat & Post Legs, Black, No Hardware | N/A | A | G | P | $1.88 | $1.98 | $1.88 | |
| RFB-1112-B-05 | 15 | Female R/A Lo-Profile PCB Mount | with D-Flat & Snap Legs, Black, No Hardware | N/A | A | G | P | $2.19 | $2.09 | $1.99 | |
| RFB-1112-W | 16 | Female R/A Lo-Profile PCB Mount | with D-Flat & post Legs, White | N/A | A | G | P | $2.00 | $1.90 | $1.80 | |
| RFB-1112-W-03 | 17 | Female R/A Lo-Profile PCB Mount | with D-Flat & Snap Legs, White | N/A | A | G | P | $2.16 | $2.06 | $1.96 | |
| RFB-1112-W-04 | 16 | Female R/A Lo-Profile PCB Mount | with D-Flat & Post Legs, White, No Hardware | N/A | A | G | P | $2.10 | $2.00 | $1.90 | |
| RFB-1112-W-05 | 17 | Female R/A Lo-Profile PCB Mount | with D-Flat & Snap Legs, White, No Hardware | N/A | A | G | P | $2.10 | $2.00 | $1.90 | |
| RFB-1112-1B | 18 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Post Legs, Black | N/A | A | G | P | $2.23 | $2.13 | $2.03 | |
| RFB-1112-1B-03 | 19 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Snap Legs, Black | N/A | A | G | P | $1.93 | $1.83 | $1.73 | |
| RFB-1112-1B-04 | 18 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Post Legs, Black, No Hardware | N/A | A | G | P | $2.87 | $2.77 | $2.67 | |
| RFB-1112-1B-05 | 19 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Snap Legs, Black, No Hardware | N/A | A | G | P | $2.98 | $2.88 | $2.78 | |
| RFB-1112-1W | 20 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Post Legs, White | N/A | A | G | P | $2.36 | $2.26 | $2.16 | |
| RFB-1112-1W-03 | 21 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Post Legs, White | N/A | A | G | P | $2.51 | $2.41 | $2.31 | |
| RFB-1112-1W-04 | 20 | Female Vertical Lo-Profile PCB Mount | with D-Flat & Post Legs, White, No Hardware | N/A | A | G | P | $2.36 | $2.26 | $2.16 | |
| RFB-1112-1W-05 | 21 | Female Vertical Lo-Profile PCB Mount | with D-Flat & snap Legs, White, No Hardware | N/A | A | G | P | $2.98 | $2.88 | $2.78 | |
| RFB-1113-B | 22 | Female R/A Hi-Profile PCB Mount | with D-Flat & Post Legs, Black | N/A | A | G | P | $2.00 | $1.90 | $1.80 | |
| RFB-1113-B-03 | 23 | Female R/A Hi-Profile PCB Mount | with D-Flat & Snap Legs, Black | N/A | A | G | P | $2.16 | $2.06 | $1.96 | |
| RFB-1113-B-04 | 22 | Female R/A Hi-Profile PCB Mount | with D-Flat & Post Legs, Black, No Hardware | N/A | A | G | P | $2.20 | $2.10 | $2.00 | |
| RFB-1113-B-05 | 23 | Female R/A Hi-Profile PCB Mount | with D-Flat & Snap Legs, Black, No Hardware | N/A | A | G | P | $2.19 | $2.09 | $1.99 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFB-1113-W | 24 | Female R/A Hi-Profile PCB Mount | with D-Flat & Post Legs, White | N/A | A | G | P | $2.00 | $1.90 | $1.80 | |
| RFB-1113-W-03 | 25 | Female R/A Hi-Profile PCB Mount | with D-Flat & Snap Legs, White | N/A | A | G | P | $2.16 | $2.06 | $1.96 | |
| RFB-1113-W-04 | 24 | Female R/A Hi-Profile PCB Mount | with D-Flat & Post Legs, White, No Hardware | N/A | A | G | P | $2.10 | $2.00 | $1.90 | |
| RFB-1113-W-05 | 25 | Female R/A Hi-Profile PCB Mount | with D-Flat & Snap Legs, White, No Hardware | N/A | A | G | P | $2.10 | $2.00 | $1.90 | |
| RFB-1113-1B | 26 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Post Legs, Black | N/A | A | G | P | $2.03 | $1.93 | $1.83 | |
| RFB-1113-1B-03 | 27 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Snap Legs, Black | N/A | A | G | P | $2.21 | $2.11 | $2.01 | |
| RFB-1113-1B-04 | 26 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Post Legs, Black, No Hardware | N/A | A | G | P | $2.19 | $2.09 | $1.99 | |
| RFB-1113-1B-05 | 27 | Female Vertical Hi-Profile PCB Mount | with D-Flat, & Snap Legs, Black, No Hardware | N/A | A | G | P | $1.92 | $1.82 | $1.72 | |
| RFB-1113-1W | 28 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Post Legs, White | N/A | A | G | P | $2.03 | $1.93 | $1.83 | |
| RFB-1113-1W-03 | 29 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Snap Legs, White | N/A | A | G | P | $2.21 | $2.11 | $1.91 | |
| RFB-1113-1W-04 | 28 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Post Legs, White, No Hardware | N/A | A | G | P | $2.54 | $2.44 | $2.34 | |
| RFB-1113-1W-05 | 29 | Female Vertical Hi-Profile PCB Mount | with D-Flat & Snap Legs, White, No Hardware | N/A | A | G | P | $2.42 | $2.32 | $2.22 | |
| RFB-1115 | 30 | Female Jack Panel Mount | 4 Hole Flange | N/A | N | G | T | $2.81 | $2.71 | $2.61 | |
| RFB-1115-S | 30 | Female Jack Panel Mount | 4 Hole Flange | N/A | S | G | T | $3.47 | $3.37 | $3.27 | |
| RFB-1115-3 | 31 | Female Vertical PCB Mount | 3 Leg | N/A | N | G | T | $1.95 | $1.85 | $1.75 | |
| RFB-1115-4 | 32 | Female Vertical PCB Mount | 4 Leg | N/A | S | G | T | $2.32 | $2.22 | $2.12 | |
| RFB-1115-5 | 33 | Female R/A PCB Mount | Short, Diecast Zinc | N/A | N | G | P | $3.57 | $3.47 | $3.37 | |
| RFB-1115-11 | 35 | Female Vertical PCB Mount | 4 Leg with .400 on Center | N/A | N | G | T | $2.53 | $2.43 | $2.33 | |
| RFB-1115-14 | 30 | Female Flange Jack | 4 Hole Flange wit .720 on Center | N/A | S | G | T | $3.78 | $3.68 | $3.58 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFB-1116 | 36 | Female Bulkhead Jack | Front Mount with D-Flat, Diecast Zinc | UG-1094A/U | N | G | D | $1.35 | $1.25 | $1.15 | |
| RFB-1116-I | 37 | Female Bulkhead Jack | Front Mount with D-Flat, Insulated | N/A | N | G | A | $2.26 | $2.16 | $2.06 | |
| RFB-1116-I-03 | 38 | Female Bulkhead Jack | Front Mount with D-Flat, Insulated, with .500 Mounting Threds, No Hardware | N/A | N | G | A | $6.20 | $6.10 | $6.00 | |
| RFB-1116-NG | 39 | Female Bulkhead Jack | Front Mount with D-Flat & Solder Lug | UG-1094A/U | N | G | T | $2.40 | $2.30 | $2.20 | |
| RFB-1116-SG | 39 | Female Bulkhead Jack | Front Mount with D-Flat | UG-1094A/U | S | G | T | $2.34 | $2.24 | $2.14 | |
| RFB-1116-3 | 36 | Female Bulkhead Jack | Front Mnt w/ D-Flat & lockwasher (No Solder Lug) | N/A | N | G | T | $2.22 | $2.12 | $2.02 | |
| RFB-1116-5 | 40 | Female Bulkhead Jack | RFI Capacitor Filtered | N/A | N | G | T | $6.29 | $6.19 | $6.09 | |
| RFB-1116-11 | 39 | Female Bulkhead Jack | Front Mount w/ Berillium Copper Contact | N/A | N | G | T | $2.75 | $2.65 | $2.55 | |
| RFB-1117 | 41 | Female Crimp Bulkhead Jack | C | Rear Mount with D-Flat & O-Ring for RG-58/U | N/A | N | G | D | $5.06 | $4.96 | $4.86 |
| RFB-1117-BT | 42 | Female Crimp Bulkhead Jack | B | Rear Mount with D-Flat & O-Ring for RG-174/U Panel Thickness .200 | N/A | N | G | T | $4.84 | $4.74 | $4.64 |
| RFB-1117-BT-03 | 42 | Female Crimp Bulkhead Jack | B | Rear Mount with D-Flat & O-Ring for RG-174/U Panel THickness .140 | N/A | N | G | T | $4.84 | $4.74 | $4.64 |
| RFB-1117-B1-T | 42 | Female Crimp Bulkhead Jack | B1 | Rear Mount with D-Flat & O-Ring for RG-316 Double Shield, Panel Thickness .200 | N/A | N | G | T | $5.77 | $5.67 | $5.57 |
| RFB-1117-C1 | 41 | Female Crimp Bulkhead Jack | C1 | Rear Mount with D-Flat & O-Ring for RG-142/U | N/A | N | G | D | $5.86 | $5.76 | $5.66 |
| RFB-1117-C2 | 41 | Female Crimp Bulkhead Jack | C2 | Rear Mount with D-Flat & O-Ring for Times LMR-200 | N/A | N | G | D | $6.11 | $6.01 | $5.91 |
| RFB-1121 | 44 | Female Twist-On Jack | C | for RG-58/U | N/A | N | S | D | $2.29 | $2.19 | $2.09 |
| RFB-1123-C1 | 45 | Female Crimp Jack | C1 | for RG-142/U | N/A | N | G | T | $2.71 | $2.61 | $2.51 |
| RFB-1123-C2 | 45 | Female Crimp Jack | C2 | for Times LMR-200 | N/A | N | G | T | $4.28 | $4.18 | $4.08 |
| RFB-1123-1 | 45 | Female Crimp Jack | C | for RG-58/U | N/A | N | G | T | $2.29 | $2.19 | $2.09 |
| RFB-1124-1P | 45 | Female Crimp Jack | P | for Proflex | N/A | N | G | D | $2.05 | $1.95 | $1.85 |
| RFB-1124-1X | 45 | Female Crimp Jack | X | for RG-8X & Times LMR-240 | N/A | N | G | D | $1.78 | $1.68 | $1.58 |
| RFB-1143 | 46 | Male Bulkhead Plug | Front Mount with D-Flat | N/A | N | G | T | $3.06 | $2.96 | $2.86 | |
| RFB-1150 | 47 | Male Termination | 1/2 Watt, 1.5 HHz | N/A | N | G | D | $1.74 | $1.64 | $1.54 | |
| RFB-1150-1 | 48 | Male Termination | 1/2 Watt, 1.5 Hz, with Chain | N/A | N | G | D | $1.66 | $1.56 | $1.46 | |
| RFB-1154 | 49 | Female Right Angle Bulkhead Jack | Front Mount w/ Solder pot, O-Ring & D-Flat | N/A | N | G | T | $5.29 | $5.19 | $5.09 | |
| RFB-1160 | 50 | Female Crimp Jack | C | Wall Plate FlushRear Mount with D-Flat for RG-58/U (LAN) | N/A | N | G | D | $2.98 | $2.88 | $2.78 |
| RFB-1161 | 51 | Female Twist-On Jack | C | Wall Plate Flush Rear Mount with D-Flat for RG-58/U (LAN) | N/A | N | G | D | $2.08 | $1.98 | $1.88 |
  |
|
|
