| PART # | Fig | Description | CBL GRP | NOTES |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RSA-3000-A | 1 | Male Crimp Plug | A | for RG-178/U | N | G | T | $3.70 | $3.60 | $3.50 |
| RSA-3000-B | 1 | Male Crimp Plug | B | for RG-174/U | N | G | T | $2.68 | $2.58 | $2.48 |
| RSA-3000-B1 | 1 | Male Crimp Plug | B1 | for RG-316/U Double Shield | N | G | T | $4.26 | $4.16 | $4.06 |
| RSA-3000-C | 2 | Male Crimp Plug | C | for RG-58/U | N | G | T | $2.76 | $2.66 | $2.56 |
| RSA-3000-C1 | 2 | Male Crimp Plug | C1 | for RG-142/U | N | G | T | $2.94 | $2.84 | $2.74 |
| RSA-3000-C2 | 2 | Male Crimp Plug | C2 | for Times LMR-200 | N | G | T | $3.10 | $3.00 | $2.90 |
| RSA-3000-I | 3 | Male Crimp Plug | I | for Belden 9913 & Times LMR-240 | N | G | T | $5.50 | $5.40 | $5.30 |
| RSA-3000-X | 4 | Male Crimp Plug | X | for RG-8X & Times LMR-240 | N | G | T | $3.08 | $2.98 | $2.88 |
| RSA-3000-1B | 1 | Male Crimp Plug | B | for RG-174/U | G | G | T | $3.63 | $3.53 | $3.43 |
| RSA-3000-1B1 | 1 | Male Crimp Plug | B1 | for RG-316/U Doube Shield | G | G | T | $3.87 | $3.77 | $3.67 |
| RSA-3000-1C | 2 |
Male Crimp Plug |
C | for RG-58/U | G | G | T | $3.11 | $3.01 | $2.91 |
 |
| PART # | Fig | Description | CBL GRP | NOTES |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RSA-3010-1B | 5 | Male Right Angle Crimp Plug | B | for RG-174/U | N | G | T | $4.52 | $4.42 | $4.32 |
| RSA-3010-B | 5 | Male Right Angle Crimp Plug | B | for RG-174/U | N | G | T | $5.21 | $5.11 | $5.01 |
| RSA-3010-B1 | 5 | Male Right Angle Crimp Plug | B1 | for RG-316/U Double Shielad | N | G | T | $5.37 | $5.27 | $5.17 |
| RSA-3010-C | 6 | Male Right Angle Crimp Plug | C | for RG-58/U | N | G | T | $4.66 | $4.56 | $4.46 |
| RSA-3010-C1 | 6 | Male Right Angle Crimp Plug | C1 | for RG-142/U | N | G | T | $4.60 | $4.50 | $4.40 |
| RSA-3010-C2 | 6 | Male Right Angle Crimp Plug | C2 | for Times LMR-200 | N | G | T | $5.38 | $5.28 | $5.18 |
| RSA-3010-X | 6 | Male Right Angle Crimp Plug | X | for RG-8X & Times LMR-240 | N | G | T | $6.86 | $6.76 | $6.66 |
| RSA-3010-7 | 6 | Male Right Angle Crimp Plug | M | for Motorola White Teflon, Belden 89907 | N | G | T | $5.26 | $5.16 | $5.06 |
| RSA-3010-7-B | 6 | Male Right Angle Crimp Plug | B | Stainless Steel Nut with Gold Body, for RG-174/U | N | G | T | $10.52 | $10.42 | $10.32 |
| RSA-3050-B | 7 | Female Crimp Jack | B | for RG-174/U | N | G | T | $4.03 | $3.93 | $3.83 |
| RSA-3050-B1 | 7 | Female Crimp Jack | B1 | for RG-316/U Double Shield | N | G | T | $4.53 | $4.43 | $4.33 |
| RSA-3050-C | 7 | Female Crimp Jack | C | for RG-58/U | N | G | T | $4.11 | $4.01 | $3.91 |
| RSA-3050-C1 | 7 | Female Crimp Jack | C1 | for RG-142/U | N | G | T | $4.34 | $4.24 | $4.14 |
| RSA-3050-C2 | 8 | Female Crimp Jack | C2 | for Times LMR-200 | N | G | T | $4.03 | $3.93 | $3.83 |
| RSA-3050-X | 8 | Female Crimp Jack | X | for RG-8X & Times LMR-240 | N | G | T | $4.34 | $4.24 | $4.14 |
| RSA-3100-B | 10 | Male Clamp Plug | B, B1 | for RG-174/U & RG-316/U Double Shield | N | G | T | $3.97 | $3.87 | $3.77 |
| RSA-3100-C | 11 | Male Clamp Plug | C, C1 | for RG-58/U & RG-142/U | N | G | T | $5.57 | $5.47 | $5.37 |
| RSA-3110-B | 12 | Male Right Angle Clamp Plug | B, B1 | for RG-174/U & RG-316/U Double Shield | N | G | T | $5.57 | $5.47 | $5.37 |
| RSA-3110-C | 12 | Male Right Angle Clamp Plug | C, C1 | for RG-58/U & RG-142/U | N | G | T | $5.73 | $5.63 | $5.53 |
| RSA-3200 | 13 | Male Bulkhead Plug | N/A | Front Mount with Solder Cup & D-Flat | N | G | T | $4.90 | $4.80 | $4.70 |
| RSA-3200-1 | 13 | Male Bulkhead Plug | N/A | Front Mount with Solder Cup & D-Flat | G | G | T | $5.91 | $5.81 | $5.71 |
| RSA-3221 | 15 | Male Crimp Panel Mount Plug | N/A | 2 Hole Flange with Solder Cup | N | G | T | $5.33 | $5.23 | $5.13 |
 |
| PART # | Fig | Description | CBL GRP | NOTES |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RSA-3231 | 17 | Male Panel Mouny Plug | N/A | 4 Hole Flange with Solder Cup | N | G | T | $5.49 | $5.39 | $5.29 |
| RSA-3231-1 | 17 | Male Panel Mount Plug | N/A | 4 Hole Flange with Solder Cup | G | G | T | $5.90 | $5.80 | $5.70 |
| RSA-3250 | 18 | Female Bulkhead Jack | N/A | Front Mount wiyh Solder Cup & D-Flat | N | G | T | $4.52 | $4.42 | $4.32 |
| RSA-3251 | 19 | Female Bulkhead Jack | N/A | Rear Munt with Solder Cup & D-Flat | N | G | T | $4.36 | $4.26 | $4.16 |
| RSA-3251-1-10 | 20 | Female Bulkhead Jack | N/A | Rear Mount with Solder CUp, Hex Flange, D-Flat & O-Ring | G | G | T | $4.92 | $4.82 | $4.72 |
| RSA-3252-A-4 | 21 | Female Crimp Bulkhead Jack | A | Reverse Polarity [Gender], for RG-178/U | N | G | T | $4.02 | $3.92 | $3.82 |
| RSA-3252-B | 21 | Female Crimp Bulkhead Jack | B | Rear Mount with D-Flat, for RG-174/U | N | G | T | $4.60 | $4.50 | $4.40 |
| RSA-3252-B-03 | 22 | Female Crimp Bulkhead Jack | B | Rear Mount with Gasket & D-Flat, for RG-174/U | N | G | T | $7.83 | $7.73 | $7.63 |
| RSA-3252-B1 | 21 | Female Crimp Bulkhead Jack | B1 | Rear Mount w/ D-Flat, for Rg-316/U Double Shield | N | G | T | $5.08 | $4.98 | $4.88 |
| RSA-3252-C | 23 | Female Crimp Bulkhead Jack | C | Rear Mount with D-Flat, for RG-58/U | N | G | T | $4.12 | $4.02 | $3.92 |
| RSA-3252-C1 | 23 | Female Crimp Bulkhead Jack | C1 | Rear MOunt with D-Flat, for RG-142/U | N | G | T | $4.66 | $4.56 | $4.46 |
| RSA-3261 | 27 | Female Panel Mount Jack | N/A | 2 Hole Flange with Solder Cup | N | G | T | $5.28 | $5.18 | $5.08 |
| RSA-3262 | 28 | Female Panel Mount Jack | N/A | 2 Hole Flange with Post Terminal | N | G | T | $5.34 | $5.24 | $5.14 |
| RSA-3263 | 29 | Female Panel Mount Jack | N/A | 2 Hole Flange with Socket Contact | N | G | T | $6.24 | $6.14 | $6.04 |
| RSA-3268 | 30 | Female Panel Mount Jack | N/A | 2 Hole Flange with .196 Extended Dielectric & Post Terminal | N | G | T | $5.69 | $5.59 | $5.49 |
| RSA-3269 | 31 | Female Panel Mount Jack | N/A | 2 Hole Flange with .590 Extended Dielectric & Post Terminal | N | G | T | $5.60 | $5.50 | $5.40 |
 |
| PART # | Fig | Description | CBL GRP | NOTES |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RSA-3270-C | 32 | Female Crimp Panel Mount Jack | C | 4 Hole Flange, for RG-58/U | N | G | T | $5.73 | $5.63 | $5.53 |
| RSA-3271 | 33 | Female Panel Mount Jack | NA | 4 Hole Flange with Solder Cup | N | G | T | $5.27 | $5.17 | $5.07 |
| RSA-3279 | 34 | Female Panel Mount Jack | N/A | 4 Hole Flange with .590 Extended Dielectric & Post Terminal | N | G | T | $5.27 | $5.17 | $5.07 |
| RSA-3285-03 | 35 | Female Panel Mount Jack | N/A | 4 Hole Right Angle Flange with Post Terminal | N | G | T | $6.22 | $6.12 | $6.02 |
| RSA-3300 | 36 | Female Right Angle PCB Mount | N/A | N/A | N | G | T | $5.76 | $5.66 | $5.56 |
| RSA-3300-03 | 37 | Female Right Angle Bulkhead PCB Mount | N/A | N/A | N | G | T | $6.40 | $6.30 | $6.20 |
| RSA-3300-1 | 36 | Female Right Angle PCB Mount | N/A | N/A | G | G | T | $6.36 | $6.26 | $6.16 |
| RSA-3300-1-03 | 37 | Female Right Angle Bulkhead PCB Mount | N/A | N/A | G | G | T | $6.53 | $6.43 | $6.33 |
| RSA-3350 | 38 | Female Vertical PCB Mount | N/A | N/A | N | G | T | $3.60 | $3.50 | $3.40 |
| RSA-3350-1 | 38 | Female Vertical PCB Mount | N/A | N/A | G | G | T | $3.95 | $3.85 | $3.75 |
| RSA-3500-085 | 39 | Male Plug | SR1 | for .085 Semi-Rigid Cable | N | G | T | $2.61 | $2.51 | $2.41 |
| RSA-3500-1-085 | 39 | Male Plug | SR1 | for .085 Semi-Rigid Cable | G | G | T | $2.92 | $2.82 | $2.72 |
| RSA-3500-141 | 39 | Male Plug | SR2 | for .141 Semi-Rigid Cable | N | G | T | $2.61 | $2.51 | $2.41 |
| RSA-3500-1-141 | 39 | Male Plug | SR2 | for .141 Semi-Rigid Cable | G | G | T | $2.92 | $2.82 | $2.72 |
| RSA-3510-085 | 40 | Male Right Angle Plug | SR1 | for .085 Semi-Rigid Cable | N | G | T | $4.96 | $4.86 | $4.76 |
| RSA-3510-1-085 | 40 | Male Right Angle Plug | SR1 | for .085 Semi-Rigid Cable | G | G | T | $5.00 | $4.90 | $4.80 |
| RSA-3510-141 | 40 | Male Right Angle Plug | SR2 | for .141 Semi-Rigid Cable | N | G | T | $2.42 | $2.32 | $2.22 |
| RSA-3510-1-141 | 40 | Male Right Angle Plug | SR2 | for .141 Semi-Rigid Cable | G | G | T | $5.00 | $4.90 | $4.80 |
| RSA-3550-085 | 41 | Female Panel Mount Jack | SR1 | 2 Hole Flange for .085 Semi-Rigid Cable | N | G | T | $4.68 | $4.58 | $4.48 |
| RSA-3550-1-085 | 41 | Female Panel Mount Jack | SR1 | 2 Hole Flange for .085 Semi-Rigid Cable | G | G | T | $5.00 | $4.90 | $4.80 |
| RSA-3555-SR1 | 42 | Female Jack | SR1 | for .085 Semi-Rigid Cable | N | G | T | $2.82 | $2.72 | $2.62 |
| RSA-3555-SR2 | 42 | Female Jack | SR2 | for .141 Semi-Rigid Cable | N | G | T | $2.37 | $2.27 | $2.17 |
| RSA-3555-1SR1 | 42 | Female Jack | SR1 | for .085 Semi-Rigid Cable | G | G | T | $3.15 | $3.05 | $2.95 |
| RSA-3555-1SR2 | 42 | Female Jack | SR2 | for .141 Semi-Rigid Cable | G | G | T | $2.80 | $2.70 | $2.60 |
| RSA-3555-1-047 | 42 | Female Jack | SR0 | for .047 Semi-Rigid Cable | G | G | T | $2.87 | $2.77 | $2.67 |
| RSA-3560-1-SR1 | 43 | Female Bulkhead Jack | SR1 | Rear Mount, for .085 Semi-Rigid Cable | G | G | T | $3.09 | $2.99 | $2.89 |
| RSA-3560-141 | 43 | Female Bulkhead Jack | SR2 | Rear Mount, for .141 Semi-Rigid Cable | N | G | T | $4.37 | $4.27 | $4.17 |
| RSA-3570-085 | 44 | Female Panel Mount Jack | SR1 | 4 Hole Flange for .085 Semi-Rigid Cable | N | G | T | $4.68 | $4.58 | $4.48 |
 |
|
|
