| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFN-1000-C2 | 1 | Male Clamp Plug | C2 | for Times LMR-200 | N/A | N | G | T | $6.18 | $6.08 | $5.98 |
| RFN-1000-C2S | 1 | Male Clamp Plug | C2 | for Times LMR-200 | N/A | S | G | T | $6.30 | $6.20 | $6.10 |
| RFN-1000-N | 1 | Male Clamp Plug | C, C1 | for RG-58/U & RG-142/U | UG-536B/U | N | G | T | $5.52 | $5.42 | $5.32 |
| RFN-1000-1S | 1 | Male Clamp Plug | C, C1 | for RG-58/U & RG-142/U | UG-536A/U | S | G | T | $5.35 | $5.25 | $5.15 |
| RFN-1001-S | 2 | Male Solder Plug | C, C1, C2, D, E, F, I, P, X | ** | N/A | S | G | T | $4.99 | $4.89 | $4.79 |
|
**for Cable Group C, C1, C2 use with Reducer RFU-530 for Cable Groups D, P & X use with Reducer RFU-531 Connector will Accept Maxuimum Cener Conductor of OD .100 [2.74] |
|||||||||||
| RFN-1002-PL | 3 | Male Clamp Plug | PL | for Belden 89913 Plenum | N/A | S | G | T | $6.28 | $6.18 | $6.08 |
| RFN-1002-1N | 3 | Male Clamp Plug | E | for RG-8/U | UG-21B/U, D/U, E/U | N | G | T | $5.44 | $5.34 | $5.24 |
| RFN-1002-1S | 3 | Male Clamp Plug | E | for RG-8/U | UG-21B/U, D/U, E/U | S | G | T | $5.69 | $5.59 | $5.49 |
| RFN-1002-1SI | 3 | Male Clamp Plug | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $5.57 | $5.47 | $5.37 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFN-1002-2L2 | 4 | Male Clamp Plug | L2 | For times LMR-600 | N/A | S | G | T | $12.47 | $12.37 | $12.27 |
| RFN-1004-1SP | 1 | Male Clamp Plug | P | for Proflex | N/A | S | G | T | $4.94 | $4.84 | $4.74 |
| RFN-1004-1SX | 1 | Male Clamp Plug | X | for RG-8/X & Times LMR-240 | N/A | S | G | T | $5.44 | $5.34 | $5.24 |
| RFN-1005-B-03 | 5 | Male Crimp Plug | B | for RG-174/U | N/A | N | G | T | $4.60 | $4.50 | $4.40 |
| RFN-1005-B1-03 | 5 | Male Crimp Plug | B1 | for RG-316/U Double Shield | N/A | N | G | T | $5.50 | $5.40 | $5.30 |
| RFN-1005-C1 | 5 | Male Crimp Plug | C1 | for RG-142/U | N/A | N | G | T | $4.53 | $4.43 | $4.33 |
| RFN-1005-C2 | 5 | Male Crimp Plug | C2 | for Times LMR-200 | N/A | N | G | T | $4.70 | $4.60 | $4.50 |
| RFN-1005-C2S | 5 | Male Crimp Plug | C2 | for Times LMR-200 | N/A | S | G | T | $4.81 | $4.71 | $4.61 |
| RFN-1005-1SR1 | 6 | Male Plug | SR1 | for .085 Semi-Rigid | N/A | N | G | T | $4.00 | $3.90 | $3.80 |
| RFN-1005-1SR2 | 6 | Male Plug | SR2 | for .141 Semi-Rigid | N/A | N | G | T | $11.93 | $11.83 | $11.73 |
| RFN-1005-2N | 5 | Male Crimp Plug | C | for RG-58/U | N/A | N | G | T | $4.03 | $3.93 | $3.83 |
| RFN-1005-3C | 5 | Male Crimp Plug | C | for RG-58/U | N/A | S | G | T | $4.13 | $4.03 | $3.93 |
| RFN-1005-3C1 | 5 | Male Crimp Plug | C1 | for RG-142/U | N/A | S | G | T | $4.39 | $4.29 | $4.19 |
| RFN-1005-5 | 7 | Male Crimp Plug | C | Quick Disconnect, for RG-58/U | N/A | S | G | T | $4.17 | $4.07 | $3.97 |
| RFN-1005-7 | 5 | Male Crimp Plug | M | for Motorol White Teflon or Belden 89907 | N/A | S | G | T | $4.39 | $4.29 | $4.19 |
| RFN-1006-PL | 8 | Male Crimp Plug | PL | for Belden 89913 Plenum | N/A | S | G | T | $5.28 | $5.18 | $5.08 |
| RFN-1006-2L2 | 9 | Male Crimp Plug | L2 | for Times LMR-600 | N/A | S | G | T | $9.56 | $9.46 | $9.36 |
| RFN-1006-3E | 8 | Male Crimp Plug | E | for RG-8/U | N/A | S | G | T | $4.18 | $4.08 | $3.98 |
| RFN-1006-3F | 8 | Male Crimp Plug | F | for RG-214/U | UG-1682/U | S | G | T | $4.18 | $4.08 | $3.98 |
| RFN-1006-3I | 8 | Male Crimp Plug | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $4.36 | $4.26 | $4.16 |
| RFN-1007-2SP | 5 | Male Crimp Plug | P | for Proflex | N/A | S | G | T | $4.86 | $4.76 | $4.66 |
| RFN-1007-2SX | 5 | Male Crimp Plug | X | for RG-8/X & Timex LMR-240 | N/A | S | G | T | $4.76 | $4.66 | $4.56 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFN-1009-B-03 | 10 | Male Right Angle Crimp Plug | B | Square Body, for RG-174/U | N/A | N | G | T | $7.15 | $7.05 | $6.95 |
| RFN-1009-C | 11 | Male Right Angle Crimp Plug | C | for RG-58/U | N/A | S | G | T | $9.48 | $9.38 | $9.28 |
| RFN-1009-C-03 | 10 | Male Right Angle Crimp Plug | C | Square Body, for RG-58/U | N/A | S | G | T | $7.96 | $7.86 | $7.76 |
| RFN-1009-C1 | 11 | Male Right Angle Crimp Plug | C1 | for RG-142/U | N/A | S | G | T | $11.42 | $11.32 | $11.22 |
| RFN-1009-C2 | 11 | Male Right Angle Crimp Plug | C2 | for Times LMR-200 | N/A | S | G | T | $11.57 | $11.47 | $11.37 |
| RFN-1009-PL | 11 | Male Right Angle Crimp Plug | PL | for Belden 89913 Plenum | N/A | S | G | T | $11.45 | $11.35 | $11.25 |
| RFN-1009-X-04 | 12 | Male Right Angle Crimp Plug | X | for RG-8/X & Times LMR-240 | N/A | N | G | T | $7.00 | $6.90 | $6.80 |
| RFN-1009-3E | 11 | Male Right Angle Crimp Plug | E | for RG-8/U | N/A | S | G | T | $13.62 | $13.52 | $13.42 |
| RFN-1009-3I | 11 | Male Right Angle Crimp Plug | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $9.44 | $9.34 | $9.24 |
| RFN-1020-1 | 13 | Female Panel Mount | N/A | 2 Hole Flange | N/A | S | G | T | $4.71 | $4.61 | $4.51 |
| RFN-1021 | 14 | Female Flange Jack | N/A | 4 Hole Flange | UG-58A/U | S | G | T | $4.60 | $4.50 | $4.40 |
| RFN-1021-1 | 15 | Female Flange Jack | N/A | 4 Hole Flange with Removable Pin & Flush Dielectric | UG-58A/U | S | G | T | $4.61 | $4.51 | $4.31 |
| RFN-1021-2 | 14 | Female Flange Jack | N/A | 4 Hole Flange | UG-58A/U | N | G | T | $4.10 | $4.00 | $3.90 |
| RFN-1021-4 | 16 | Female Flange Jack | N/A | MIni 4 Hole Flange w/ Post Terminal, .705 Extended Dialectric & O-Ring | N/A | N | G | T | $4.60 | $4.50 | $4.40 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFN-1021-5 | 17 | Female Flange Jack | N/A | Mini 4 Hole Flange w/ Post Terminal, .190 Extended Dielectric & O-Ring | N/A | N | G | T | $4.28 | $4.18 | $4.08 |
| RFN-1021-6 | 18 | Female Clamp Panel Mount | C, C1 | 4 Hole Flange, for RG-58/U & RG-142/U | UG1095A/U, B/U, B/U | S | G | T | $7.25 | $7.15 | $7.05 |
| RFN-1021-14 | 19 | Female Flange Jack | N/A | 4 Hole Flange with Slotted Terminal Contact | N/A | N | G | T | $4.79 | $4.69 | $4.59 |
| RFN-1022 | 20 | Female Bulkhead | N/A | Front Mount | N/A | S | G | T | $4.56 | $4.46 | $4.36 |
| RFN-1022-SR1 | 21 | Female Bulkhead | SR1 | Rear Mount with Double D-Flat, for .085 Semi-Rigid Cable | N/A | N | G | T | $6.70 | $6.60 | $6.50 |
| RFN-1022-SR2 | 21 | Female Bulkhead | SR2 | Rear Mount with Double D-Flat, for .141 Semi-Rigid Cable | N/A | N | G | T | $6.70 | $6.60 | $6.50 |
| RFN-1022-SR3 | 21 | Female Bulkhead | SR3 | Rear Mount with Double D-Flat, for .250 Semi-Rigid Cable | N/A | N | G | T | $6.70 | $6.60 | $6.50 |
| RFN-1022-1 | 20 | Female Bulkhead | N/A | Front Mount with Double D-Flat | UG-680/U, /U | S | G | T | $3.81 | $3.71 | $3.61 |
| RFN-1022-3 | 22 | Female Bulkhead | N/A | Front Mount, Long with Double D-Flat | N/A | S | G | T | $5.78 | $5.68 | $5.58 |
 |
| PART # | Fig | Description | CBL GRP | NOTES | REPLACES OR EQUIVALENT TO |
PLATING BDY |
PLATING P/C |
PLATING DIE |
PRICE QTY. 10-49 |
PRICE QTY. |
PRICE QTY. |
| RFN-1022-5 | 23 | Female Bulkhead | N/A | Front Mount with D-Flat & O-Ring | N/A | N | G | T | $2.87 | $2.77 | $2.67 |
| RFN-1022-8 |
24 |
Female Crimp Bulkhead | B | Rear Mount with O-Ring, for RG-174/U | N/A | N | G | T | $7.33 | $7.23 | $7.13 |
| RFN-1022-8-B1 | 24 | Female Crimp Bulkhead | B1 | Rear Mount w/ O-Ring, for RG-316/U Double Shield | N/A | N | G | T | $7.55 | $7.45 | $7.35 |
| RFN-1022-8-C | 24 | Female Crimp Bulkhead | C | Rear Mount with O-Ring, for RG-58/U | N/A | N | G | T | $5.41 | $5.31 | $5.21 |
| RFN-1022-8-C1 | 24 | Female Crimp Bulkhead | C1 | Front Mount with O-Ring, for RG-142/U | N/A | N | G | T | $6.01 | $5.91 | $5.81 |
| RFN-1024-PL | 25 | Female Clamp Jack | PL | for Belden 89913 Plenum | N/A | S | G | T | $6.10 | $6.00 | $5.90 |
| RFN-1024-1 | 25 | Female Clamp Jack | E | for RG-8/U | UG-23D/U, F/U | S | G | T | $3.97 | $3.87 | $3.77 |
| RFN-1024-1SI | 25 | Female Clamp Jack | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $5.52 | $5.42 | $5.32 |
| RFN-1025-C2 | 26 | Female Clamp Jack | C2 | for Times LMR-200 | N/A | S | G | T | $4.12 | $4.02 | $3.92 |
| RFN-1025-1 | 26 | Female Clamp Jack | C, C1 | for RG-58/U & RG-142/U | N/A | S | G | T | $4.60 | $4.50 | $4.40 |
| RFN-1026-1P | 25 | Female Clamp Jack | P | for Proflex | N/A | S | G | T | $3.84 | $3.74 | $3.64 |
| RFN-1026-1X | 25 | Female Clamp Jack | X | for RG-8/X & Times LMR-240 | N/A | S | G | T | $5.33 | $5.23 | $5.13 |
| RFN-1027 | 27 | Female Crimp Jack | C | for RG-58/U | N/A | S | G | T | $4.21 | $4.11 | $4.01 |
| RFN-1027-C1 | 27 | Female Crimp Jack | C1 | for RG-142 | N/A | S | G | T | $4.71 | $4.61 | $4.51 |
| RFN-1027-C2 | 27 | Female Crimp Jack | C2 | for Times LMR-200 | N/A | S | G | T | $3.98 | $3.88 | $3.78 |
| RFN-1028 | 28 | Female Crimp Jack | E | for RG-8/U | Amph. 82-0337 | S | G | T | $4.52 | $4.42 | $4.32 |
| RFN-1028-PL | 28 | Female Crimp Jack | PL | for Belden 89913 Plenum | N/A | S | G | T | $4.57 | $4.47 | $4.37 |
| RFN-1028-SI | 28 | Female Crimp Jack | I | for Belden 9913 & Times LMR-400 | N/A | S | G | T | $4.28 | $4.18 | $4.08 |
| RFN-1028-2L2 | 29 | Female Crimp Jack | L2 | for Times LMR-600 | N/A | S | G | T | $8.80 | $8.70 | $8.60 |
| RFN-1029-SP | 27 | Female Crimp Jack | P | for Proflex | N/A | S | G | T | $3.79 | $3.69 | $3.59 |
| RFN-1029-SX | 27 | Female Crimp Jack | X | for RG-8/X & Times LMR-240 | N/A | S | G | T | $3.92 | $3.82 | $3.72 |
| RFN-1041-1 | 30 | Male Panel Mount | N/A | 4 Hole Flange | N/A | S | G | T | $6.18 | $6.08 | $5.98 |
  |
|
|
